Olefin Unit-SINOSEAL

Ethylene compressor OEM: SBW Equipment model：3MCL1005+MCL1004 Seal model：GCTL02/L Medium：Ethylene Temp.：-100/-23.8℃ Inlet Press.：0.117/0.674 MPaA Outlet Press.：0.674/1.17 MPaA Speed：3886 RPM Running well since operation in 2013

Kunlun Energy Hubei Huanggang LNG

Propylene compressor OEM: SBW Equipment model：3MCL1407 Seal model：GCTL02/L Medium：Propylene Temp.：-40℃ Inlet Press.：0.1309 MPaA Outlet Press.：1.78MPaA Speed：3033 RPM Running well since operation in 2013

CNOOC Huizhou Petrochemical

1MTA Ethylene unit Dry gas compressor Tag No.：K-800 Seal model：S747L Medium ：H2、O2、C2H6、C3H8、C3H6 Inlet Temp. ：39.7℃ Outlet Temp. ：92℃ Inlet Press.：0.6192MPa Outlet Press.：3.3588MPa Speed：14190rpm Shaft OD ：123mm OEM：SBW Equipment model：3MCL409 In operation since 2018

CNOOC Shell Huizhou Petrochemical

1MTA Ethylene unit Ethylene product pump Tag No.：2101-P-690A/S Seal model：CM1Bn/11G Medium ：Ethylene Temp. ：-45/-33/65℃ Inlet Press.：1.735MPa Outlet Press.：2.179MPa Speed：1475rpm API plan：14+72+76 OEM：DDBP Equipment model：LDB 400-25*4-B-A In operation since 2015

CNOOC Shell Huizhou Petrochemical

1MTA Ethylene unit Ethane circulation pump Tag No.：2101-P-445A/S Seal model：CMB021/01G Medium ：C2 Temp. ：-75/-39/65℃ Inlet Press.：0.746MPa Outlet Press.：0.987MPa Speed：2920rpm API plan：11+72+76 OEM：Sulzer Dalian Equipment model：ZE 80-2200 In operation since 2015

North Huajin Chemical

Ethylene unit cracked gas compressor Medium ：Cracked gas Temp. ： 40/85.4 ℃ Seal model：CMB021/01G Speed： 5477 rpm Inlet Press.： 0.126 MPaA Outlet Press.： 3.90 MPaA OEM: SBW Equipment model：DMCL904+2MCL904+2MCL807 Running well since operation in Aug. 2019

CNPC Sichuan Petrochemical

Ethylene cracking unit propylene rectification tower conveying pump Seal model：CM1Bn/1G Temp. ：47.8 ℃ Press.：19.5bar Speed：1460rpm PLAN 11+72+76 OEM：Sulzer Dalian Equipment model：CD8 In operation since 2013

Sinopec Zhenhai Petrochemical

Ethylene unit Panoil pump Medium ：Panoil Temp. ：169.1℃ Seal model：H122/H122 Inlet Press.：0.31MPaA Outlet Press.：0.95MPaA API plan：plan32+61 Speed：1470rpm OEM: DDBP Running well since operation in 2017

Sinopec Zhenhai Petrochemical

Ethylene unitQuench oil pump Medium ：Quench oil； Temp. ：195℃ Seal model：H123-1206--E02889 Inlet Press.：0.12MPaA Outlet Press.：1.4MPaA API plan：32+62 Speed：1475rpm OEM: Shin Nippon Machinery Running well since operation in 2017

Sinopec Zhenhai Petrochemical

Ethylene unit Quench water pump Medium ：Quench water Tag No.: P-156A/B/C/D Temp. ：83℃ Seal model：H104 Inlet Press.：0.131 MPaA Outlet Press.：1.39MPaA API plan：23 Speed：1485rpm Seal Model：H104 OEM: Flowserve Italy Equipment Model：12HDSS-294 Running well since operation in 2017

Sinopec Qilu Petrochemical

Ethylene unit Quench oil pump Tag NO.：GA-104ABC Medium ：Quench oil Temp. ：195℃ Seal model：H104 Inlet Press.：0.106MPaA Outlet Press.：1.163MPaA API plan：plan32+53A Seal Model：CMB021W/B021 Speed：1490rpm OEM: Ebara Equipment Model：500x300KST.80 Running well since operation in 2015
